Model : ADH-12500



When arc is struck,Auto- darkening Filter will turn from clear state to dark state,response time is less than 1/25000S.



With non-grade adjustable shade number from DIN7-DIN12



The high performance of Auto-darkening Filter provides to the user?s eyes and face a full protection against UV and IR radiation during the entire welding process,even in the clear state.



Delay time fast or slow can be selective.



Sensitivity adjustment:you can according your working conditions,adjusting sensitivity(low or high) of the darkening filter.at the MIG welding or other small electric ARC welding can choose high sensitivity.



Filter cassette size:110*90*8.5mm (4.33" x 3.54" x 0.33")



View window size:92 x 42mm.(3.62" x 1.65")



UV/IR protection:Up to shade DIN 15



Clear state Shade No:DIN 4



Dark state Shade No:DIN7-DIN12 stepless adjustment



Sensitivity:low or high can be selective



Power supply:solar cells, Nobattery change required



Power on/off:Fully Automatic



Response time:



A) Clear to dark:<=1/25000S



B) Dark to Clear:0.2-0.5S



Work temperature:-10-+55C



Storing temperature:-20-+70C



Gross weight:450G
