Pro'skit SS-989B 2 In 1 SMD HotAirReworkStation(AC 220V) 70W

larger image

Model: SS-989B (SS-989C)
Manufactured by: PRO'SKIT

RM607.60 RM560.00
Save: 8% off

Add to Cart:

Features

2 in 1 Rework Station to save the cost
Antistatic soldering iron and hot air desoldering 2 in 1 design to save the cost
Closed Circuit Sensor Design
Closed-loop temperature control for accurate and air-flow-independent temperature
High Power, Quick Warm Up Times
High heating power, warm up quickly, adjustable temperature and air flow for easy surface or hole mount components QFP, SOP type IC devices rework.
Individual Function Start Save Energy
Individual function starts save energy, or share function by 2 users at the same time, three knobs control hot air volume, hot air temperature, and soldering iron temperature
LED Digital Display
Digital LED displays for both rework and soldering station
Applicable to most of branded nozzles and tips
High Quality heating element and nozzles, also applicable to most of branded heating element and nozzles
Quiet in operation
Diaphragm pump with maximum capacity at 24L/min, equipment noise less than 45dB, wind volume and temperature are adjustable, suitable for many kinds of use
Auto Cool-Off Process to prolong the life of heating element
After power switch is turned off, the auto cool-off process leaves the blower on until the nozzle is cool in order to prolong the life of heating element and to ensure safety
ESD Safe Design
Prevent static and leakage electric to damage the PCB
Interchangeable and applicable to most of branded hot air nozzles and tips
Interchangeable hot air nozzles design for different type of surface mount components. 3 nozzles included with this rework station.

Product Name?SS-989B

Specification

Product Name?SS-989B

Power Input		220V / 50Hz
Power Consumption		700W
Soldering Power		60W
Temperature Range		200~ 480°C
De-soldering Temperature Range		100°C ~ 420°C
Heating Element		Metal Heating Core
Pump/Motor Type		Diaphragm Pump
Air Capacity		24L/min?max?
Equipment noise		45dB
Temperature Display		LED
Dimensions		330(L) x 275(W) x 195(H)mm
Weight		3700g
Accessories
Soldering Stand	1pcs
Soldering Iron 60W	9SS-900-SI
Replacement Nozzle:	9SS-900-A1 (2.2mm) x 1pcs 9SS-900-A2 (6.6mm) x 1pcs 9SS-900-A3 (8.5mm) x 1pcs
