Sanwa CD771 Digital Multimeter

  • Model: CD771
  • Shipping Weight: 0.57kg
  • Manufactured by: SANWA

RM415.00

Add to Cart:
Image result for ready stock
Description:

Sanwa CD771 Digital Multimeter

3-3/4 digits 4000 count

Backlight & Cont. buzzer with LED

3-3/4 digits 4000 count
Easy to read large LCD with Backlight
Large breaking capacity fuse 30kA
1.5V battery check function
Thermo plastic elastomer, high resistance  against drop shock
Safety cap on current terminal
Data hold, Range hold, Relative function
Continuity check, Diode test
Auto power off function (30min.)
Maximum 20A can be measured if the measurement  time is less than 10 seconds.

 Dimension : 17.3cm x 13.6cm x 7.2cm

(Take 10 minutes or  longer intervals between measurements)
Display : numeral display 4000
Sampling rate : 3 times / sec.
AC frequency bandwidth : 40
400Hz (sine wave)

DC Voltage 400mV to 1000V
AC Voltage 4V to 1000V
Resistance 400Ω to 40MΩ
Frequency 5 Hz to 100kHz
Capacitance 50nF to 100μF
DC Current 400μA to 10A
AC Current 4μA to 10A
Continuity Check Buzzer sounds in a range of 0 to 130Ω. Open voltage at approx DC 0.4V
Diode Test Open voltage at approx DC 1.5V
Dimensions H166 x W82 x D44
Weight 360g




This product was added to our catalog on Friday 10 January, 2014.
