Model: JZS-16 is a Drilling & Tapping machine.

Featureas

• Belt driven in an even keel
• Drilling and tapping
• Good quality of electric components for long life using
• Equipped with pedal switch and easy to operate

Specifications

Max. tapping capacity (Cast iron / Steel) : M16 / M12

Max. drilling capacity : 16mm

Diameter of column : 85mm

Spindle travel : 93mm

Distance spindle axis to column surface : 180mm

Max. distance spindle nose to worktable : 425mm

Max distance spindle nose to base : 610mm

Spindle taper : MT.2

Spindle speeds range : 160 - 1820rpm

Spindle speeds : 9

Dimension of worktable surface : 270mm x 280mm

Dimension of base worktable surface : 245mm x 245mm

Overall height : 1050mm

Motor : 750W

Weight : 108kg
