Kyoritsu 2117R Digital Clamp Meter

  • Model: KE 2117R
  • Shipping Weight: 0.53kg
  • Manufactured by: KYORITSU

RM333.00

Qty Discounts Off Price
1
RM333.00
2
RM332.00
3-4
RM331.00
5+
RM330.00
Add to Cart:

Image result for ready stock

Can't wait for tomorrow? same day delivery can be arrange for Klang Valley customers! (Please call us at 03-42702333 for arrangement)



  Fully Safety jaw
Ergonomic over-molded body gives convenient one-hand operation
Large easy-to-read display with 0.01A resolution
Accurate reading with True RMS
60/600/1000A auto-ranging
Long battery life




Safety Standard
IEC 61010-1 CAT IV 300V / CAT III 600V







AC A
60.00/600.0/1000A (Auto-ranging)
±1.5%rdg±4dgt [45 - 65Hz]
  ±2.0%rdg±5dgt [40 - 1kHz]
AC V
60.00/600.0V (Auto-ranging)
±1.0%rdg±2dgt [45 - 65Hz] (600V)
  ±1.5%rdg±4dgt [40 - 1kHz]
DC V
60.00/600.0V (Auto-ranging)
±1.0%rdg±3dgt (60V)
±1.2%rdg±3dgt (600V)
Ω
600.0Ω/6.000/60.00/600.0kΩ (Auto-ranging)
±1.0%rdg±5dgt (600Ω)
  ±2.0%rdg±3dgt (6/60/600kΩ)
Continuity buzzer 600Ω
Conductor size φ33mm max.
Applicable standards IEC 61010-1 CAT IV 300V, CAT III 600V Pollution degree 2
IEC 61010-031, IEC 61010-2-032, IEC 61010-2-033,
IEC 61326-2-2, IEC 60529, EN50581 (RoHS)
Power source R03/LR03 (AAA) (1.5V) × 2
Continuous measuring time Approx.170 hours (Auto power save : approx. 10 minutes)
Dimensions 204(L) × 81(W) × 36(D)mm (23.8 x 11.5 x 6.5cm)
Weight 220g Approx. (including batteries)
Accessories 7066A (Test leads),  9079(Carrying case), R03 (AAA) × 2,
Instruction Manual
Optional




This product was added to our catalog on Monday 02 May, 2016.
